Lithium-Ion Battery Storage Cabinets-Type 90

Lithium-Ion Battery Storage Cabinets-Type 90

5000.0 INR/Unit
Get a Price/Quote

Product Details:

  • Features Automatic Door Closing, Smoke Detector, Integrated Ventilation, Fire Protection, Acid-Resistant Coating, Emergency Ventilation, Grounding Connection, Over-temperature Alarm, Exhaust Connection, Adjustable Shelves
  • Temperature Resistance Up to 90 Minutes Fire Resistance at 1000C
  • Display Type Digital Display Panel
  • Heating Capacity Not applicable (no heating function)
  • Glass Type Multi-layer Fireproof Glass (Viewing window on doors)
  • Control Type Mechanical & Electronic Lock
  • Shape Rectangular
  • Click to view more
Request To Call Back Send Inquiry
X

Lithium-Ion Battery Storage Cabinets-Type 90 Price And Quantity

  • 5000.0 INR/Unit
  • 1 Number

Lithium-Ion Battery Storage Cabinets-Type 90 Product Specifications

  • 230 Litres
  • Type 90
  • Stainless Steel, High-Grade Fireproof Sheet Steel
  • Electric, 220V AC
  • 220 W
  • Rectangular
  • Mechanical & Electronic Lock
  • Battery Storage Cabinet
  • Multi-layer Fireproof Glass (Viewing window on doors)
  • 1200 x 600 x 1980 mm
  • 220V / 50Hz
  • Powder Coated Steel
  • Digital Display Panel
  • Not applicable (no heating function)
  • Up to 90 Minutes Fire Resistance at 1000C
  • Automatic Door Closing, Smoke Detector, Integrated Ventilation, Fire Protection, Acid-Resistant Coating, Emergency Ventilation, Grounding Connection, Over-temperature Alarm, Exhaust Connection, Adjustable Shelves
  • Safe Storage of Lithium-Ion Batteries
  • Removable and Height-Adjustable Shelves, Spill Retention Tray
  • Indoor
  • Active Ventilation Unit with Filter System
  • Audio/Visual Alarm, Over-temperature and Smoke Detection
  • Double Lock (Key and Digital Code)
  • Yellow (Standard Safety Color)
  • 2
  • Approx. 320 kg
  • Double Door, Self-Closing
  • Freestanding

Lithium-Ion Battery Storage Cabinets-Type 90 Trade Information

  • 3 Week

Product Description

The lithium-Ion battery charging cabinet is suitable for the storage and charging of various types of

power tool batteries. The cabinet complies with the FM6050 standard and OSHA 1910.106 of the

American Occupational Safety and Health Association and the NFPA 30 regulations of the American

Fire Protection Association;

2. A highly sensitive smoke detector is installed on the top of the cabinet. When the smoke detector

detects smoke, the buzzer on the front of the cabinet will sound an alarm, and the fan will

automatically cut off the power to prevent the fire from spreading outward;

3. The cabinet is equipped with steel shelves as standard, and each shelf has multiple heat dissipation

ventilation holes to increase the air flow inside the cabinet;

4. The cable connection port has a fireproof function, and the cable connection inside and outside the

cabinet is sealed with fireproof putty;

5. The PDU socket has an automatic power-off function. When the smoke detector alarms, the socket

can automatically disconnect the power supply to avoid accidents;

6. The cabinet has leakage protection and overload protection functions;

7. Working voltage: AC 220V/50Hz;

8. Built-in fan to eliminate the heat generated by charging, the exhaust port can be automatically

closed at 74C to avoid fire spillover;

9. Standard PUD industrial socket, you can choose different types of sockets such as European

standard sockets and British standard sockets;

10. Standard circuit installation to effectively avoid safety hazards caused by line fire;


Specifications

Model No

Fission012B

Dimensions, Exterior

59x46x89cm (W*D*H)

Color

Blue

Dimensions, Interior

51x38x79cm (W*D*H)

Numbers of shelf

2 pc

Extraction air

75 DN



Number of Doors

1

Operating Voltage

AC 220V/50Hz



Door Type

Self-Closing

Fire Resistance

10 minutes







Superior Fire Protection for Lithium-Ion Batteries

Engineered for maximum safety, this Type 90 cabinet withstands fires for up to 90 minutes at 1000C. The double-layer doors self-close, sealing the contents from flames. Integrated over-temperature and smoke detectors trigger immediate audio/visual alerts, ensuring quick incident response in battery storage areas.


Intelligent Design for Efficient Storage

With adjustable height shelves and a spill retention tray, the cabinet allows customizable storage for batteries of different sizes. The large 230-litre capacity, coupled with easy-clean, acid-resistant interiors, guarantees both ample space and durability for daily operations in industrial or laboratory settings.


Comprehensive Safety and Security Features

A double-lock system that combines mechanical keys with digital codes secures contents effectively. Active ventilation with filtration, emergency ventilation options, and a digital display panel provide real-time status. The cabinet's robust construction and grounding connection mitigate risks associated with battery storage.

FAQ's of Lithium-Ion Battery Storage Cabinets-Type 90:


Q: How does the Type 90 Lithium-Ion Battery Storage Cabinet protect against fire hazards?

A: This cabinet is built with high-grade fireproof sheet steel and powder-coated stainless steel, and can resist fire for up to 90 minutes at 1000C. It features self-closing double doors, an integrated over-temperature and smoke detection system, as well as automatic alarms for enhanced emergency response.

Q: What usage process should be followed when storing lithium-ion batteries in this cabinet?

A: Users should place batteries on the removable, height-adjustable shelves, ensuring not to exceed the 230-liter capacity. The spill retention tray catches leaks, and batteries should be evenly distributed. Always lock both the mechanical and electronic locks after loading, and check the digital display panel for ventilation and alarm statuses.

Q: When should the internal alarms be expected to activate?

A: The cabinet's audio/visual alarms will activate if an over-temperature situation or smoke is detected inside. This immediate notification system helps prevent incidents by prompting rapid evacuation or fire suppression measures.

Q: Where is the best location to install the cabinet for optimal safety?

A: Recommended for indoor environments, the cabinet should be installed on a level, freestanding spot away from direct heat sources or sunlight. Ensure good accessibility for emergency response, and proper ventilation connections for the active exhaust system.

Q: What is the benefit of the cabinet's active ventilation and filter system?

A: Active ventilation reduces the risk of hazardous vapors accumulating inside the storage cabinet. The filter system captures dangerous particles, maintaining air quality and supporting compliance with workplace safety standards, especially during charging or discharging of stored batteries.

Q: How is the security of stored batteries ensured in the cabinet?

A: The double lock mechanism, featuring both a physical key and a digital code, restricts unauthorized access. The cabinet's robust build and locking system, combined with audio/visual alarm alerts, guarantee secure battery storage against both theft and hazardous incidents.

Q: What materials make the cabinet resistant to chemical and fire damage?

A: The cabinet is constructed from powder-coated stainless steel and high-grade fireproof sheet steel, with an acid-resistant coating and multi-layer fireproof glass on the viewing windows. These materials ensure the cabinet resists fire, corrosion, and chemical spills often associated with lithium-ion battery storage.
