Standard Features |
Sample compartment | Lifts out for cleaning |
Cuvet racks and compartments | 2 included with dedicated compartments |
Included cuvets | 1cm plastic (quantity 10) |
Standard Interfaces | USB-B for connection to a remote computer USB-A for connection to a printer or USB memory device |
Languages | On-board software in English, Spanish, French, German and Italian |
Power Requirements | 100240V, 50/60Hz (selected autom) Specifications | Optical Design | Single Beam | Spectral Bandwidth | <= 4nm | Light Source | Tungsten-halogen | Detector | 2048 element CCD | Wavelength | Range | 340nm - 1000nm | Accuracy | 2nm | Repeatability | 1nm | Data interval | 1nm | Photometric | Range | -0.3 A to 2.5 A | Readout | ABS, %T, Concentration | Accuracy | 0.01A at 0.3A 0.05A at 1.0A (SPECTRONIC standard filters measured at 590nm) | Repeatability | 0.3%T at 50%T | Stray Light | <0.2%T (with SPECTRONIC standard SRM 400 filter) | Display | Variable angle 320 x 240 pixel color graphical LCD 2.75 in. 2 in., 3.4 in. diagonal (75cm, 8.6cm diagonal) | Keypad | Sealed tactile rubber | atically) |
