Lithium-Ion Battery Charing Cabinet

Product Description

Lithium-ion charging cabinet serves as a secure storage and charging solution for lithium-ion batteries

within the workplace. Equipped with 8 charging outlets and an in-built containment sump, the cabinet

addresses safety concerns associated with high temperatures that may lead to electrolyte leakage or

combustion in lithium-ion batteries. Designed with fan to draw in cool air and extract hot air, promoting airflow to cool the batteries effectively, making it suitable for the hot Australian environment. These cabinets are built tough with a double-wall construction and 40mm thermal barrier, offering enhanced protection in the event of a workplace fire. Ensuring compliance with safety standards, the cabinet is equipped with danger and warning signage, including a Class 9 lithium battery warning diamond. Complies with AS NZS 4681 and AS 1940

Frame Structure: 1.2mm double-layer galvanized steel plate, 40mm fireproof partition, 150mm high

containment sump to capture any leaks of electrolyte, double doors with automatic closing. Shelves: Standard configuration includes 1pc perforated 2.0mm galvanized sheets, adjustable height

spacing 76mm, shelf load capacity 100Kg. Standard Accessories: Grounding terminal, warning signs, adjustable feet, one exhaust fan. Exhaust Fan Parameters: Voltage 220V/50Hz, Current 0.13A, Power 21W, Speed 2600RPM, Airflow:

2.373/min (142.2 m3/h). Equipment Voltage: 220V/50Hz. Sockets: 1pc Australian standard 10A PDU sockets, 8 outlets per socket, total 8 outlets, with double- break switch. Waterproof leakage protection circuit breaker: 32A. Power socket: Bent-type industrial waterproof, dustproof, and corrosion-resistant Australian standard 20A plug and socket, IP66. Internal socket ports: One 15A Australian standard sockets (2 positions total) for powering the PDU

socket and fan power cord;

Specifications
