SHIMADZU ANALYTICAL BALANCE

SHIMADZU ANALYTICAL BALANCE

Product Details:

X

Product Description

SHIMADZU ANALYTICAL BALANCE AUW220D

DESCRIPTION
It is spacious enough to place samples with ease, regardless of their shape. Doors open wide in three directions. Extra room allows samples to align with the chamber temperature before measurement. The level gauge is installed at the best visible position, and the all-metal structure ensures high durability and quality of exterior case. We know that even these seemingly small considerations contribute to accuracy and efficiency. AW Series meets any imaginable demand on an analytical balance both in accuracy and in features.

SPECIFICATIONS
Model AUW 220 D
Capacity 220 g / 82 g
Minimum Display 0,1 mg /0,01 mg
Repeatability (Standard deviation, s) = 0,1 mg (large range)

Linearity ± 0,2 mg (large range) ± 0,1 mg (small range)
Response Time (stabilization time, typical) 3 s (large range) 15 s (small range)
Calibration weights Built-in
Operating ambient temperature 5 to 40°C
Temperature coefficient of sensitivity (10 to30°C)
±2ppm° C (When PSC is Off)
Sensitivity stability against temperature change
(when PSC is ON, 10 - 30°C)± 2 ppm
Pan size approx. 80 mm diameter
Body dimensions approx. 220 mm (W) x 330mm (D) x 310 (H)
Weight approx. 7 kg
Power consumption approx. 7 W



NATIONAL ANALYTICAL CORPORATION

* Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.
