Portable pH/ORP Meter

100 INR/Piece

Get a Price/Quote

Product Details:

Interface Type BNC and pin connector for temperature probe
Equipment Type Portable pH/ORP Meter
Accuracy pH: Â±0.01; ORP: Â±1 mV
Resolution pH: 0.01 pH; ORP: 1 mV
Display Type Large LCD
Automation Grade Manual
Number of Specimens Single sample measurement at a time
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Portable pH/ORP Meter Price And Quantity

Minimum Order Quantity 3-4 Piece
Price Range 100.00 - 1000.00 INR/Piece
Price 100 INR/Piece

Portable pH/ORP Meter Product Specifications

Usage Field and laboratory
Control Mode Manual key operation
Response Time < 30 seconds
Mounting Type Handheld
Power Supply 2 x 1.5V AA batteries
Equipment Type Portable pH/ORP Meter
Interface Type BNC and pin connector for temperature probe
Resolution pH: 0.01 pH; ORP: 1 mV
Accuracy pH: Â±0.01; ORP: Â±1 mV
Display Type Large LCD
Temperature 0Â°C to 50Â°C (operating)
Number of Specimens Single sample measurement at a time
Automation Grade Manual
Humidity Less than 85% RH
Machine Weight Approximately 250 g (including batteries)
Features Waterproof, portable, battery powered, backlit display
Port Size BNC connector for electrode
Operating Voltage 3V (2 x 1.5V AA batteries)

Portable pH/ORP Meter Trade Information

FOB Port MUMBAI
Supply Ability 3-4 Piece Per Day
Delivery Time 3-4 Week
Main Domestic Market All India
Certifications ISO CERTIFICATION

Product Description

SPECIFICATIONS:

Range	pH	-2.00 to 16.00 pH
	ORP	±699.9 mV; ±1999 mV
	Temperature	-20.0 to 120.0°C / -4.0 to 248.0°F
Resolution	pH	0.01 pH
	ORP	0.1 mV; 1 mV
	Temperature	0.1°C / 0.1°F
Accuracy	pH	±0.01 pH
	ORP	±0.2 mV; ±1 mV
	Temperature	±0.4°C / ±0.8°F
Calibration	pH	automatic, 1 or 2 point with 3 memorized buffer values (4.01, 7.01, 10.01)
	Offset	±1 pH
	Slope	75 to 110%
Input Impedance		10¹² Ohm
Temperature Compensation		Automatic, -20 to 120°C (-4 to 248°F) or manual without temperature probe
pH Electrode		HI 1230B PEI body pH electrode with BNC connector and 1 m (3.3’) cable (included)
Temperature Probe		HI 7662 stainless steel temperatures probe with 1 m cable (included)
Battery Type / Life		9V / approximately 150 hours of continuous use; auto-off after 20 minutes of non-use or disabled (user-selectable)
Environment		0 to 50°C (32 to 122°F); RH max 100%
Dimensions		164 x 76 x 45 mm (6.5 x 3.0 x 1.8")
Weight		180 g (6.3 oz.)

FEATURES:

Automatic calibration
Automatic Temperature Compensation
Automatic buffer recognition
Three standard buffer values
Calibration tags on LCD
Low battery indicator
Auto shut-off
HOLD function
ºC and ºF measurements

Precision Measurements in Any Setting

This portable pH/ORP meter is engineered for rigorous use in both laboratory and field environments, ensuring versatile application. Its waterproof and robust design enables accurate sample measurement under varied conditions. With a response time of less than 30 seconds, it delivers reliable results, making it an essential tool for professionals requiring prompt pH and ORP readings.

User-Friendly and Convenient

Equipped with a large backlit LCD and manual controls, this device enables straightforward operation, even in low-light scenarios. The data hold function allows users to freeze readings, while the low battery indicator ensures the meter is always ready for use. Its lightweight and portable nature make it ideal for users who need mobility without compromising data quality.

FAQs of Portable pH/ORP Meter:

Q: How do I operate the portable pH/ORP meter?

A: You can operate the device using its manual key controls. Simply connect the appropriate electrode via the BNC connector, power on the meter using two AA batteries, and immerse the electrode in your sample. Select your desired mode to measure either pH or ORP values.

Q: What types of environments is this meter suitable for?

A: This device is designed for both field and laboratory use. Its rugged, waterproof casing and portability ensure it can function in environments with temperatures ranging from 0C to 50C and humidity below 85% RH.

Q: When should I replace the batteries in the meter?

A: The instrument is equipped with a low battery indicator that alerts you when the AA batteries need to be replaced, ensuring continuous and accurate operation.

Q: Where can this meter be used for sample analysis?

A: Due to its portable and durable construction, the meter can be utilized in various settings, such as water treatment facilities, laboratories, agricultural fields, and research environments.

Q: What is the process for calibrating the meter for pH or ORP measurements?

A: Calibration involves connecting the electrode, selecting the desired measurement mode, and using standard calibration solutions. Manual prompts on the display guide you through the straightforward process to guarantee measurement accuracy.

Q: How does the data hold function benefit the user?

A: The data hold feature allows you to freeze the current reading on the display, making it easier to record and review measurements, especially in dynamic or low-visibility situations.
