Liquid Particle Counter

Product Description

Liquid portable particle counter

(updated from model LE 100) is mainly used for detection of insoluble particles in injection, infusion, sterile powder under USP <788> "Particulate Matter in Injections", and particle contamination detection of infusion equipment, anesthesia equipment, medical packaging materials. It can also be used for particle detection in organic, colored and transparent, oil-based liquid samples.

The instrument can not be used to detect corrosive liquids.

Application

Injections testing under CP, USP, EP, JP and other standards

Cleanliness detecting of medical equipment / parts

Filtration efficiency detection

Laboratory water testing

Features:

• Built-in USP testing
• Precise syringe sampling device, accurate sampling volume and stable speed
• Built-in calibration curve, in line with ISO-21501
• Intelligent automatic detection and automatic calibration functions, instrument performance judgment and calibration
• Magnetic stirring method, adjustable stirring speed
• USB interface directly export data, paperless electronic printing report
• Powerful application software development support. Conveniently connect to external equipment such as laboratory information management system
• LE-Assistant software realizes PC control and provides professional data processing
• Comply with 21 CFR-11 Electronic Records and Signatures rules and standards in FDA and user classification management

 Specification

Particle size range: 2~400m

Number of channel sizes:24 channels, 2~100m sizes can be set arbitrarily by user

Accuracy: 10%

Resolution: > 90% (2015 CP), <10% (USP, ISO21501)

Max. sample concentration: 10000 particles/ml

Syringe specifications: 1ml, 5ml, 10ml*, 25ml

Sample flow rate: 20 ml/min

Sample accuracy: 1%

Min. Sample volume: 0.2ml**

Sensor material:316 stainless steel, quartz glass, TEFLON

Display:7inch LCD color touch screen

Data output:RS232 port, USB, built-in printer

Power supply: AC 100~240V, 50/60HZ

Dimension: 320(l) 309(w) 394(H) mm

Weight: 11.0kg

Operating environment:Temperature 5 -40 C; Relative humidity 0 ~ 95%, non-condensing

Sample stirring method:Magnetic stirring (adjustable)

Software system: LE-Assistant

Standard configuration

Under 1ml syringe specifications the minimum sampling volume is 0.2ml, under the standard configuration, the minimum sampling volume is 0.4ml
